Description:    The LOCTITE Pro Pump Hand Held Dispenser is a bottle-mounted adhesive dispenser that can be used with 50ml or 250ml bottles of LOCTITE anaerobic adhesives creating a complete dispensing system. This dispenser utilizes patented progressive cavity pump technology that is specifically designed to dispense LOCTITE anaerobic threadlockers and retaining compounds. The multi-position nozzle delivers adhesive in three different orientations, horizontal, 45° up and 45° down and can also be folded down 90° for storage. It enables more accurate and consistent application while eliminating waste and mess.

Application: Anaerobic threadlockers and retaining compounds in 50 ml and 250 ml bottles

Benefits:

• Turns a bottle of adhesive into a dispensing system
• Prevents spills, eliminates mess and waste
• A single drop of adhesive is always ready with just a pull of the trigger
• Small, compact and lightweight

Description:     LOCTITE 98414/97001 Peristaltic Handgun is a manual, peristaltic, volumetric bottle-top hand pump applicator.

Application:     Anaerobic adhesives in 50 ml and 250 ml bottles for viscosities up to approx. 2,500 mPas.

Benefits:

• Ideal for accurate drop dispensing therefore improves quality and reduces waste
• Ensures no leakage, regardless of the orientation of the bottle
• Requires no flushing, power or air source

Description:     LOCTITE EQ RC18 Integrated Semi-Automatic Dispensing System to dispense the adhesive directly from larger bottles. The controller provides digital timing control for any LOCTITE automatic dispense valve or automatic hand-held applicator. It is equipped with a precision pressure regulator:
0.1 – 0.7 bar for viscosities < 1,500 mPas

Application:     Anaerobic, instant and light cure adhesives in 250 ml, 500 g, 1 l and 2 kg bottles

Benefits:

• Integrated design (controller and reservoir) for simple set-up and space economy
• Timer-controlled solenoid valve for air-actuated applicator
• Level sensor to give empty warning
• Capable of operating in a continuous mode for bead dispensing applications

Description:   The LOCTITE EQ PU20 Digital Peristaltic Dispenser is a reliable and effective volumetric dispenser for single-component, low viscosity adhesives. It is great for precise dosing or applications that require a specific flow rate. This dispenser is electro-mechanically operated and does not require the use of an air source. It transfers liquids via pressure displacement applied by rotor turning against a tube that carries the material from the bottle to a handheld dispense applicator.

Application:   Anaerobic, instant and light cure adhesives in 10 ml, 20 g and 30 ml packs. Solvent-free activators and oils up to a viscosity of approx. 5,000 mPas.

Benefits:

• Air-free dispensing reduces premature curing and clogging of product
• Instant reverse for vacuum suck-back; shuts off the flow of liquid and prevents dripping
• Adjustable post-delay time for vacuum setting
• Simple and convenient load mechanism for tubing replacement
• Digital motor speed adjustment and display
• Digital timer display
• “Teach In” and program memory saving function
• Multiple operating modes
• System comes complete with applicator, tubing, and nozzle tips

Description:     LOCTITE 97152 Dual Channel Controller is a versatile multi-functional controller for actuating 1 – 2 dispensing valves. Settings can be made via the membrane keypad and the rotary selector switch. Reservoir pressure is controlled via a precision pressure regulator and monitored electronically.

Application:     Depends on the supplementary equipment.

Benefits:

• 1 – 2 independent dispensing channels
• Integrated solenoid valve module
• High precision pressure regulator
• PLC interface
• Graphic display for easy menu navigation
• Online flow monitor signal evaluation
• Convenient setup and programming of even complex dispense stations
• Automatic sequencing of advance slide, rotorspray and dispense valve
• Maximum process quality by control of time, pressure and optionally flow monitoring
• PIN-locking option for setup parameters
• Full integration capability into highly automated production systems

Description:     LOCTITE 97108 2.0 l Reservoir accommodates LOCTITE bottles and is equipped with a pneumatic connection and an electrical interface for setup with all LOCTITE controllers.

Application:     Adhesive bottle sizes 250 ml, 500 g, 1 L and 2 kg

Benefits:

• Operational with semi-automatic and automatic controllers
• Low level and empty warning signals (PLC)
• Manual dump valve for pressure on/off
• Reservoir lid holder to avoid contamination

Description:    LOCTITE 98009 Light Cure Dispensing Valve is a normally-closed diaphragm valve that provides high-resolution stroke adjustment and results in consistent flow control. This valve is mainly used for light cure adhesive dispensing. This valve must be used in conjunction with a controller and product reservoir.

Application:     Light cure adhesives, retaining compounds and threadlockers from low to medium viscosities up to 2,500 mPas.

Benefits:

• Bubble-free, no-drip dispensing
• Precision adjustment of stroke to control flow
• Can be used in static position, manually or mounted directly to a robot

Description:     LOCTITE 97113 Stationary Dispense Valve with 1/4 inch feed line is designed for pressure-time applications. It is modular in design and comprises of a product shut-off valve and valve actuator, providing quick on-line serviceability. This valve has an adjustable suck-back feature to eliminate stringing and dripping. It has a double-acting cylinder that allows for adjustable opening and closing times for increased dispensing control. This valve must be used in conjunction with a controller and product reservoir.

Application:     Anaerobic and light cure adhesives with viscosities up to 10,000 mPas.

Benefits:

• Slim, lightweight, seal-less design
• Adjustable suck-back feature eliminates stringing and dripping
• Can be used in static position, manually or mounted directly to a robot

Description:     LOCTITE 97135 Diaphragm Dispense Valve is a pneumatically actuated dispense valve which is designed for use in conjunction with pressure time dispense systems. The opening of the diaphragm takes place by pressurising the internal single acting cylinder. Closure is achieved by spring force between cycles.

Application:     Anaerobic adhesives with viscosities up to 2,500 mPas.

Benefits:

• Fail-safe spring assists closing of valve upon loss of air pressure
• Internal components are PTFE to prevent premature curing
• Modular design and floating diaphragm allow for easy cleaning

Description:    LOCTITE EQ RC15 Compact Rotor Pump Controller provides all control required for both the 97611 and 97621 Compact Rotor Pumps. This controls all the dispensing parameters, such as pump speed, volume dispense, reservoir pressure and rotorspray control (if used).

Application:     Depends on the supplementary equipment.

Benefits:

• Easy menu navigation allowing users to select either the amount of product dispensed (in µL) or the dispense rate (in µL/min)
• Designed to interface seamlessly with compact rotor pump
• Touch screen display for ease of use
• Connects directly to standard LOCTITE reservoirs
• Useful for all kinds of applications: drops, beads, potting

Description:    LOCTITE EQ VA20 Volumetric Dispense Valve is a positive displacement metering valve that dispenses a precise drop of adhesive with each cycle.

Application:     Light cure adhesives with volumes from 1.5 to 12 μL

Benefits:

• High speed automation up to 180 cycles per minute
• Easily fed from any LOCTITE reservoir
• Estimated lifetime >1 million cycles
• Low maintenance requirement
• Ideal for needle bonding applications

Description:    LOCTITE 97611 Compact Rotor Pump 4.0 is a precision volumetric dispenser for accurate dispensing applications.

Application:     Anaerobic, light cure and acrylic adhesives with flow rates from 500 to 6,000 μL/min.

Benefits:

• High repeatability
• High accuracy + / -1 % valid up to 100,000mPas.
• Reversible direction of flow (suck-back) allows for an exact stoppage of the product flow
• Useful for all kinds of applications: drops, beads, potting

Description:    The LOCTITE EQ HD14 200ml Dual Cartridge Dispensers are hand-held, manually operated meter-mix dispensers. These dispensers provide a convenient, cost-effective method to apply product with minimal waste. The dispensers are compatible with 1:1, 2:1, 4:1 and 10:1 mix ratio products and are available in manual or pneumatic versions.

Application:    The LOCTITE EQ HD14 200ml Dual Cartridge Dispensers are designed for mixing and applying 2K adhesives of various chemistries in 200ml cartridges.

Benefits:

• Convenient cost-effective method of application
• Highly precise dosing results thanks to the quick air exhaust.
• Dispenser immediately achieves its maximum pressure – no power lag.
• Integrated regulator enables fine-tuning of the material flow rate.
• Fatigue free handling thanks to improved tool balance and up to 35% less weight than comparable dispensers.

Description:    LOCTITE 97002 Pneumatic Handpump is desgined for plastic and aluminum cartridges. It is a manually controlled, pneumatically operated unit. The amount and rate is controlled by the operator.

Application:    250 ml tubes and 300 ml cartridges, 1K

Benefits:

• Rapid-loading system to make cartridge changes clean and easy
• Ergonomically designed
• Simple and clean dispensing

Description:    The LOCTITE 96001 50 ml Dual Cartridge Applicator is a hand-held, manually operated dispenser. The dispenser provides a convenient, cost-effective method to apply product from 2K cartridges. It is used for 1:1 and 2:1 mix ratio products.

Application:    2K epoxy, polyurethane and hybrid products in 50 ml cartridges

Benefits:

• Convenient, cost-effective method of application
• Good ergonomic features to minimize operator fatigue

Description:    LOCTITE 98666 All Purpose Syringe Dispensing System is a digital electro-pneumatic dispensing system. The system is delivered ready for operation, including dispensing needles, cartridge adapter, cartridge holder and foot switch.

Application:     Adhesives and sealants in 10 ml, 30 ml, 55 ml and 300 ml syringes / cartridges from low to high viscosity (5 mPas to paste).

Benefits:

• Digital timing control
• Compact design to minimise workspace requirement
• Vacuum suck back to ensure no drips or run-on
• Useful for all kinds of applications: drops, beads, potting

Description:    LOCTITE 97006 Precision Syringe Dispensing System accurately dispenses adhesives or other fluids. Typical applications are the assembly of medical devices with UV adhesives and many applications directly from syringes

Application:     Adhesives and sealants in 10 ml, 30 ml, 55 ml and 300 ml syringes / cartridges from low to high viscosity (5 mPas to paste).

Benefits:

• High precision syringe dispenser for maximum dispense accuracy and control
• Digital precision regulator for accurate flow control
• Vacuum suck back to ensure no drips or run-on
• Useful for all kinds of applications: drops, beads, potting

Description:     LOCTITE 97160 Dual Rotor Pump Controller provides all the functions required to control the EQ MM25 Dual Rotor Pump providing precise control of the rotation speed. It can be interfaced with a higher ranking PLC for integration into automatic systems.

Application:     2K methyl methacrylate (MMAs), epoxy, silicone and hybrid products in 400 ml cartridges (or individual reservoirs).

Benefits:

• Easy menu navigation to allow users to select either the amount of product dispensed     (in ml) or the dispense rate (in ml/min)
• Very high repetition accuracy
• Automatic purge feature to prevent mixer nozzle curing

Description:    The LOCTITE EQ RB40 400D Benchtop Robot has a 400 x 400 x 100 mm range of operation (X,Y,Z) and has features and accessories that are custom tailored for adhesive dispensing processes. This low-cost unit is fully compliant with RIA (Robotic Industry Association) safety guidelines. Programming accessories, dispensing equipment, integration cables and mounting hardware are sold separately. This low-cost benchtop robot has 3-axis control and 120 VAC or 220 VAC operation with a 24 VDC output signal

Application:     In combination with tried and tested LOCTITE dispensing equipment, the Benchtop Robots provide maximum flexibility for complex dispensing applications. Manually loaded, they allow users to repeatedly and reliably dispense dots, beads and potting deposits. Suitable valves and syringes can be easily connected to the Benchtop Robots

Parameters:

• 3 Axes of Movement
• Range of Movement – 400mm x 400mm x 100mm (X/Y/Z)
• Accurate to within +/- 0.01mm
• Maximum Speed – PTP (X,Y): 600 mm/s, PTP (Z): 320 mm/s
• I/O Signals – 8 Inputs & 8 Outputs

Benefits:

• Independent dispense on/off purge control button on front panel allows adhesive to be purged from a dispense valve to prevent curing or for aiding initial set-up
• No special programming required
• Teach Pendant program storage capabilities allows dispense program to be easily transferred from Robot to Robot
• 100 programs, 4,000 points memory per program compact flash card
• Auto-switching power supply 95-132 VAC or 180-250 VAC
• Easily integrates with the LOCTITE Needle Calibration Kit (#1569523) for precise dispense tip location
• Over-speed error indicator prevents Robot from traveling too fast during the execution of the program

Description:     The LOCTITE EQ RB40 500D Benchtop Robot has a 500 x 500 x 100 mm range of operation (X,Y,Z) and has features and accessories that are custom tailored for adhesive dispensing processes. This low-cost unit is fully compliant with RIA (Robotic Industry Association) safety guidelines. Programming accessories, dispensing equipment, integration cables and mounting hardware are sold separately. This low-cost benchtop robot has 3-axis control and 120 VAC or 220 VAC operation with a 24 VDC output signal

Application:     In combination with tried and tested LOCTITE dispensing equipment, the Benchtop Robots provide maximum flexibility for complex dispensing applications. Manually loaded, they allow users to repeatedly and reliably dispense dots, beads and potting deposits. Suitable valves and syringes can be easily connected to the Benchtop Robots

Parameters:

• 3 Axes of Movement
• Range of Movement – 500mm x 500mm x 100mm (X/Y/Z)
• Accurate to within +/- 0.01mm
• Maximum Speed – PTP (X,Y): 600 mm/s, PTP (Z): 320 mm/s
• I/O Signals – 8 Inputs & 8 Outputs

Benefits:

• Independent dispense on/off purge control button on front panel allows adhesive to be purged from a dispense valve to prevent curing or for aiding initial set-up
• No special programming required
• Teach Pendant program storage capabilities allows dispense program to be easily transferred from Robot to Robot
• 100 programs, 4,000 points memory per program compact flash card
• Auto-switching power supply 95-132 VAC or 180-250 VAC
• Easily integrates with the LOCTITE Needle Calibration Kit (#1569523) for precise dispense tip location
• Over-speed error indicator prevents Robot from traveling too fast during the execution of the program

Description:     LOCTITE EQ CL25 LED Spot Cure Controller is the universal controller that can be interfaced with up to four individual LED curing heads.
Accessories (to be ordered separately) / Order No.:

•     EQ CL25 LED Spot Cure Controller / 1473952
•     Short LED Head 365 nm / 1984957
•     Short LED Head 405 nm / 2104788
•     Ø 3 mm Lens / 1305335
•     Ø 6 mm Lens / 1305333
•     Ø 10 mm Lens / 1305332
•     1.7 m Connector Cable / 1305339
•     3.0 m Connector Cable / 1984961
•     10 m Connector Cable / 1305337
•     UV Power Meter / 1523721


Application:     UVA and UVV curing products

Benefits:

•     No heat at curing area
•     High intensity output – up to 20 W/cm2
•     Long LED lifetime – 20,000 hours
•     Compact size controller

Description:     LOCTITE EQ CL32 LED Spot is a UV/visible light emitting light source. This system offers a high powered, portable light source capable of consistently curing many light cure products that respond to UV/ visible light. Due to its unique LED technology, it can provide instant on/off performance and consistent light output. It can be run on its rechargeable batteries or while plugged to the included wall plug adapter.

Application:     UVA and UVV curing products

Benefits:

•     Combines handheld and stationary unit in one device
•     Robust aluminium housing
•     Ergonomic finger switch
•     Rechargeable using mini-USB adapter
•     Long focus length to allow for variable handheld application

Description:     LOCTITE 97055 UVALOC 1000 chamber is the optimum UV curing chamber that is designed for manual loading and unloading of components to be cured. The emission spectrum of the lamp and radiant power capacity have been designed specifically to meet the requirements of UV curable LOCTITE adhesives.

Application:     UVA, UVC and UVV curing products

Benefits:

•     Standard unit supplied with a 1,000 W medium pressure mercury arc lamp
      to provide good tack-free and depth cure
•     Optional visible light bulb for plastic bonding
•     Optional iron-doped bulb for maximum depth of cure
•     Complete shielding of operator from exposure to UV light
•     High process safety due to the integrated UV monitoring system

Description:     The LOCTITE EQ CL30 LED Flood System is a high intensity flood system specially designed for curing LOCTITE UV and Visible Light Cure adhesives. The modular configuration consists of an LED head with connection cable and controller (ordered separately). The system is offered in either 365, or 405 nm wavelengths. Each EQ CL30 head is equipped with 144 high power LED’s and integrated reflectors, providing uniform curing across a wide area (100 mm x 100 mm). The heads can also be stacked side by side in two directions further expanding the curing area for maximum flexibility. The expected lifetime of the LED’s is more than 20.000 hours under normal operating conditions. The EQ CL30 system is compatible with manual workstations as well as automated production lines.

The LOCTITE EQ CL30 LED Flood Quad Controller supplies power and control for up to four (4) LOCTITE LED Flood Arrays. The Quad Controller has intensity adjustment for each channel, Touch screen HMI, 3 running modes: Timer, Level and Advance and 3 languages: English, German and Chinese

Items to be ordered separately / Order No.:

• EQ CL30 LED Flood Single Controller / 1359255
• EQ CL30 Quad Controller / 2257357
• EQ CL30 365nm Flood head / 2139182
• EQ CL30 405nm Flood head / 2139180
• EQ CL30 97360 LED Curing chamber / 1511839

Application:     UVA and UVV curing products

Benefits:

• High intensity at 50 mm distance (365 nm: >500 mW/cm2, 405 nm: >1,000 mW/cm2)
• Typical lifetime >20,000 hours
• LED arrays stackable side by side
• No warm-up or cool-down period required
• 144 individual LEDs > Energy efficient as LEDs produce minimal wasted energy
• 100mm x 100mm curing area
• Air cooling system maintenance free
